New Style CAT6A Field Termination Plug

Features

n
• 180° straight cable entry
• Easy, quickly, reliable and comfortable installation without using any tools
• Suitable for cabling from the smallest home networks to very large data centres
• Suitable for both Solid and Stranded CAT6A cables

Standards

n
• ANSI/TIA-568C.2 Category 6A
• IEC 60603-7 Category 6A ISO 11801 2nd Edition Class EA
• Plug IEC 60603-7
• IEEE 802.3af PoE and IEEE 802.3at PoE+ applications

Mechanical Data

n
• Housing and cover material: Zinc die-casting with nickel plated
• Insertion force: 30N max. (IEC 60603-7)
• Retention strength: 7.7kg between jack and plug
• Operating temperature: -10℃~60℃ (ISO/IEC 11801, ANSI/TIA-568C.2)
• Mating cycles: 750 cycles minimum
• IDC mating cycles: 20 installation cycles minimum

Technical Date

n
• Cable entrance diameter range : 4.5mm~8.5mm
• Insulation diameter range : 0.95mm~1.45mm
• Solid and Stranded conductor : 22AWG~26AWG (0.686mm~0.241mm)
• Wire scheme : T568A / T568B
