0.25M Slim CAT6 UTP Patch Cable LSZH in Brown
search
  • 0.25M Slim CAT6 UTP Patch Cable LSZH in Brown

0.25M Slim CAT6 UTP Patch Cable LSZH in Brown

CB-SLC6-0.25BWN

$3.00
inc GST Usually dispatched within 1-3 business days
0.25M Slim CAT6 UTP Patch Cable LSZH in Brown
Quantity



Security policy



Delivery policy



Return policy

Introduction

Many global brand name manufacturers have developed small diameter patch cords in order to solve issues with today’s commonly used patch cords, such as limited spaces for cable management, restricted airflow, and the inflexibility of the cables.

This slim 28AWG UTP Snagless cable is a perfect answer to the above problems. It is great for high density spaces such as telecommunication rooms and data centres. The cable diameter is only 3.8mm, making it almost half of the size of the standard CAT6 cable. This makes it very easy to install, and the cable management job much nicer and tidier.

Features

  1. This slim CAT6 Patch cord exceeds the limits of all patch cords’ electrical performance.
  2. This 28AWG slim patch cord occupies around ½ space of the commonly used patch cords. It enables simplified cable management, improves airflow and reduces pathway fill and operation costs.
  3. This 28AWG slim patch cord improves the flexibility of MAC – Move, Add and Change.
  4. This 28AWG slim patch cord is much softer than normal CAT6 cables. It provides tighter bend radius to reach ultimate flexibility in cable routing, dressing and management.
  5. The cable jacket is LSZH ( Low Smoke Zero Halogen ) which describes a cable jacket material that is non-halogenated and flame retardant. This type of jacket material has excellent fire safety characteristics of low smoke, low toxicity and low corrosion. This type of cable jacket material is used in applications such as Central Offices, Mass Transit Rail Systems, Nuclear Plants and Oil Refineries or in any other application where the protection of people and equipment from toxic and corrosive gasses is critical.
  6. This cable comes with a snagless boot to protect the latch tab from being damaged. The connector is 50u Gold plated.
  7. The conductor is 100% pure Copper.
  8. Pass Fluke DTX-1800 Tests

Compliance

Australian Standard Approval AS/CA S008/2010

IEC 60603-7

LSZH jacket meets IEC 60754-2, IEC 61034-1 and IEC 61034-2

TIA568C.2, Max. Length 10M



Specifications



CB-SLC6-0.25BWN
100 Items
New
Comments (0)
No customer reviews for the moment.

Viewed products

16 other products in the same category:

Conductor Material Bare Copper
Structure 28AWG, 7 x 0.127mm
Insulation Material HDPE
Structure 0.63mm
Foil Screen Material N/A
Thickness N/A
Braid Material N/A
Structure N/A
Rip cord N/A
Drain Wire Material N/A
Structure N/A
Sheath Material LSZH
Thickness 0.51mm
OD 3.8 ± 0.2mm
Bending Radius (without load)   Min. 8 x Cable Diameter
Temperature Range Installation Temperature  0 to 50℃
Storage Temperature -20 to 70℃ (Under static condictions)
Operation Temperature -20 to 60℃ (Under static condictions)
Conductor Resistance @20℃ Max. 22.3 Ohms/100m Resistance Unbalance @20℃ Between pairs: 5% Max.
Dielectric Strength 2.5KV DC or 1.5KV AC for 2secs
Mutual Capacitance 5.6 nF/100m @1kHz Max. Capacitance Unbalance (Pair to Ground @20℃) 330 pF/100m @1kHz
Transfer Impedance (Max.) N/A
Coupling Attenuation (<1GHz)
Mean Characteristic Impedance 100 Ohms ± 5 Ohms @100MHz Nominal Velocity Propagation 67.60%
Max. Delay Skew @20℃ 45 nsec/100m @ 100MHz
Transmission Characteristics
FREQ RL NEXT PS-NEXT Prop. Delay
MHz (min. dB at 20℃) (min. dB) (min. dB) (max. ns)
1 20 74.3 72.3
