1.5M Red Small Diameter CAT6A 10G F/UTP 28AWG Cable LSZH ( Component Test )

Description

The new KONIX small diameter CAT6A cable is a great solution for high density patching applications. It improves the cable density and provides less cross section area. This helps improve air flow and rack ventilation. The data rate of this cable is rated to 10Gbps with a bandwidth of up to 500Mhz. It’s high performance is ensured with individual Fluke component test. It’s ready for your project use.

 Features:

• The KONIX small diameter CAT6A cable is constructed with a F/UTP cable which contains a foil shield under the cable jacket. Inside this CAT6A F/UTP cable, each pair of cable is twisted and separated by a cross separator. All 4 unshielded pairs are wrapped with a metal foil. The foil shield can act to prevent EMI/RFI from the adjacent cables or equipment. Moreover, the foil shield can also prevent the data from leaking out of the cable.

• All KONIX CAT6A small diameter cables pass the ACMC lab tests and Fluke DSX-8000 component level tests. They are all with the RCM marking and ready for project /data centre uses
• Nominal cable jacket OD is 4.6mm. Compared to the 26AWG S/FTP CAT6A cable, this small diameter CAT6A cable reduces the cable size by 24% . It has 38% smaller cross section area.
• With LSZH Jacker - LSZH (Low Smoke Zero Halogen). The Low smoke zero halogen cable is popular as it is environmentally friendly, flame-retardant, resistant and ageing, which can provide fire safety and emits less toxic gas in case of burning. It is required by most data centres today.
• The KONIX CAT6A S/FTP cable plug features a snagless design which can protect the locking clips on the RJ45 connectors from being damaged or snapped off during installation
• Meets Category 6A plug to plug electrical and transmission parameters.
• Foil Shielded ( F/UTP ) with drain wire design for EMI/RFI protection.
• The RJ45 plug used for this cable has 50 micron Gold Plated contacts which offers maximum data performance and corrosion resistance.

Application

• Data centres and enterprise communications
• High Density patching
• Confined space patching
• High-speed Ethernet transmission
• 10Gbps high-speed voice, video and data applications
• Power over Ethernet ( PoE ) such as Wireless Access Point, Thermal Camera, VoiP, etc. Supports PoE Standard IEEE802.3bt Type 3 ( 60W )

Specifications

RJ45 Plug

• Housing: 2 row, Polycarbonate, UL 94V-0, transparent colour
• Wire bar: 2 row, OD 0.65 mm, polycarbonate, UL94V-0, transparent colour
• Contact Pin materials: Phosphor Bronze with Nickel plated
• Contact Pin finished: Minimum 50 Micro-inches on surface contact area
• Shielding area: Bronze with Nickel plated
• The structure complies with IEC60603-7 requirement

Strain Relief

• Boot assembly type, OD 5.0mm. polycarbonate material, UL 940V-0, transparent colour
• Tube: transparent heat shrink tube
• Foil: Adhesive Aluminium foil

Cable

• CAT6A F/UTP 4 twisted pair

The cable performance complies with the IEC 61156-5 requirement

• Jacket OD: 4.6 mm , 0.55mm thickness
• Conductor: 28AWG Solid Bare Copper
• Isolation: HDPE
• Cross Bar: PE
• Shield: Aluminium foil / PET around all 4 pairs
• Drain Wire : Tinned Copper-clad steel, 7x 0.10mm
• Performance: The performance is complied with the ISO/IEC11801 CAT6A Patch Cord Component Requirement

Cable Wiring

• KONIX Small Diameter CAT6A cable follows T568A wiring method as as shown on below diagram:

 Available Colours:

• 10 Colours are available: Black, Blue, Red, Orange, Pink, Yellow, Green, Purple, Grey and White.

Available lengths:

• 0.25M, 0.5M,1M,1.5M, 2M, 3M, 5M, and 10M

Installation Information

Electrical Characteristics ( ANSI / TIA-568.2-D )

DC Resistance	Max. 23.6Ω/100mat 20ËšC for each conductor ( UL 444 )
DC Resistance Unbalance	Max. 5% within a pair at 20ËšC
DC Resistance Unbalance Pair-Pair	n/a
Dielectric Strength	1KV d.c./0.7KV a.c. for 1min. or 2.5KV d.c./1.7KV a.c. for 2s ( IEC61156-5 )
Insulation Resistance	5000MΩ/km ( IEC61156-5 )
Mutual Capacitance	5.6nf/100m. 1kHz at 20ËšC
Capacitance Unbalance pair-ground	Max. 330pF/100m. 1Khz at 20ËšC
Transfer Impedance	n/a
Coupling Attenuation	n/a
Phase delay	Max. 536ns/100m at 500Mhz
Delay Skew	Max. 45ns/100m, from 1 to 500Mhz at 20ËšC, 40ËšC & 60ËšC
Nominal Velocity Impedance	69% at 100Mhz
Characteristic Impedance	100± 5Ω at 100Mhz
PoE	60Vd.c 4PPoE 60W. IEEE802.3bt Type-3
